Using SR-IOV with OpenStack Ansible
- 13 minsSR-IOV is a specification that allows a PCIe device to appear to be multiple separate physical PCIe devices. A two-port NIC might be broken up into multiple physical functions (PF) with multiple virtual functions (VF) per physical function. Instead of attaching to a tuntap interface, a virtual machine instance can be connected to a virtual function and gain better performance and lower latency.
Having first worked with SR-IOV between the Mitaka and Newton cycles of OpenStack, a recent troubleshooting effort really strained my brain, so to speak. As a result, I put together some steps necessary to deploy the SR-IOV agent and related configuration in an OpenStack environment deployed with OpenStack-Ansible.
The upstream documentation for SR-IOV is a good starting point that can fill in the blanks:
https://docs.openstack.org/neutron/rocky/admin/config-sriov.html
Getting started
In this walkthrough, the following hardware/software was used:
- HP Proliant DL360e G8
- HP 530SFP+ NIC (QLogic/Broadcom NetXtreme II BCM57810)
- Ubuntu 16.04 LTS Operating System
- OpenStack Ansible (Rocky)
In my environment, the NIC used for SR-IOV is an HP 530SFP+ 2x10G Network Interface Card based on the QLogic/Broadcom BCM57810 chipset. Many NICs, including those made by Intel, Mellanox, QLogic and others support SR-IOV. SR-IOV support can be determined using lspci -s -vvv <pci bus id>, where the pci bus id corresponds to the installed NIC, like so:
root@hp02-qlogic:~# lspci -vvv -s 0000:08:00.1
08:00.1 Ethernet controller: Broadcom Corporation NetXtreme II BCM57810 10 Gigabit Ethernet (rev 10)
Subsystem: Hewlett-Packard Company Ethernet 10Gb 2-port 530SFP+ Adapter
Physical Slot: 1
...
Capabilities: [1b8 v1] Alternative Routing-ID Interpretation (ARI)
ARICap: MFVC- ACS-, Next Function: 0
ARICtl: MFVC- ACS-, Function Group: 0
Capabilities: [1c0 v1] Single Root I/O Virtualization (SR-IOV)
IOVCap: Migration-, Interrupt Message Number: 000
IOVCtl: Enable+ Migration- Interrupt- MSE+ ARIHierarchy-
IOVSta: Migration-
Initial VFs: 64, Total VFs: 64, Number of VFs: 8, Function Dependency Link: 01
VF offset: 71, stride: 1, Device ID: 16af
Supported Page Size: 000005ff, System Page Size: 00000001
Region 0: Memory at 00000000f35f0000 (64-bit, prefetchable)
Region 4: Memory at 00000000f3570000 (64-bit, prefetchable)
VF Migration: offset: 00000000, BIR: 0
Capabilities: [220 v1] #15
Kernel driver in use: bnx2x
Kernel modules: bnx2x
The PCI Bus ID can be determined using the ethtool command shown here:
root@hp02-qlogic:~# ethtool -i ens2f1
driver: bnx2x
version: 1.712.30-0
firmware-version: bc 7.14.62
expansion-rom-version:
bus-info: 0000:08:00.1 <---- PCI Bus ID
supports-statistics: yes
supports-test: yes
supports-eeprom-access: yes
supports-register-dump: yes
supports-priv-flags: yes
To support SR-IOV, the VT-d and/or VT-x extensions must be enabled in the BIOS. If applicable, SR-IOV support must be enabled in the BIOS as well. In addition, you must enable IOMMU support at boot. To do so, edit the GRUB config and add the following kernel parameter:
intel_iommu=on
Run update-grub or equivalent for your operating system and reboot the machine.
Configuring overrides
Neutron’s SR-IOV implementation involves a mechanism driver and respective agent that runs on the compute nodes. It can co-exist with other ML2 drivers including Open vSwitch and LinuxBridge, the default for OpenStack-Ansible deployments. The type of port determines which agent is responsible for the plumbing: a normal port would be handled by the Open vSwitch or Linux Bridge agent, while a direct port will be handled by the SR-IOV agent. This detail isn’t so important now, but will be when spinning up instances.
To get started, take note of the name of the interface(s) to be used for SR-IOV. Update the user_variables.yml file at /etc/openstack_deploy/user_variables.yml and specify the following overrides to enable SR-IOV within OpenStack:
neutron_plugin_types:
- ml2.sriov
nova_pci_passthrough_whitelist: '{ "physical_network":"<provider label>", "devname":"<interface>" }'
In my environment, the provider label is vlan (default for OSA) and the interface is ens2f1:
neutron_plugin_types:
- ml2.sriov
nova_pci_passthrough_whitelist: '{ "physical_network":"vlan", "devname":"ens2f1" }'
The whitelist can match on many other interface characteristics, including bus address, vendor id, and more. Refer to the documentation at https://docs.openstack.org/openstack-ansible-os_neutron/latest/configure-network-services.html for other ways to match.
OpenStack-Ansible can dynamically build provider mappings using information specified in the provider_networks block found in openstack_user_config.yml:
- network:
container_bridge: "br-vlan"
container_type: "veth"
container_interface: "eth11"
type: "vlan"
range: "101:200,301:400"
net_name: "vlan"
group_binds:
- neutron_openvswitch_agent
In this example, a provider label named vlan will be constructed and mapped to the br-vlan bridge. The br-vlan bridge may exist as a Linux bridge or a vSwitch when the OVS driver is used. The range of VLAN IDs are available for auto-allocation to tenant/project networks.
When using SR-IOV, Neutron maps a provider label to a physical interface and allocates an associated virtual function to a port when attached to a VM. The sriov_host_interfaces variable can be used to specify the interfaces, like so:
- network:
container_bridge: "br-vlan"
container_type: "veth"
container_interface: "eth11"
type: "vlan"
range: "101:200,301:400"
net_name: "vlan"
sriov_host_interfaces: "ens2f1"
group_binds:
- neutron_openvswitch_agent
- neutron_sriov_nic_agent
With the configuration above, Neutron will configure the SR-IOV agent and map the vlan provider label to the ens2f1 interface.
In some environments, network variables are managed on a per-host basis. The following example demonstrates how compute nodes can have varying configurations, such as differences in physical interfaces (ens1f0 vs ens2f1):
compute_hosts:
compute2:
ip: 172.29.236.16
container_vars:
neutron_provider_networks:
network_types: "vlan"
network_vlan_ranges: "vlan:200:230"
network_mappings: "vlan:br-vlan"
network_sriov_mappings: "vlan:ens1f0"
nova_pci_passthrough_whitelist: '{ "physical_network":"vlan", "devname":"ens1f0" }'
compute3:
ip: 172.29.236.18
container_vars:
neutron_provider_networks:
network_types: "vlan"
network_vlan_ranges: "vlan:200:230"
network_mappings: "vlan:br-vlan"
network_sriov_mappings: "vlan:ens2f1"
nova_pci_passthrough_whitelist: '{ "physical_network":"vlan", "devname":"ens2f1" }'
Be careful to avoid duplicating overrides found here in user_variables.yml, as vars specified in user_variables.yml are global. In other words, if nova_pci_passthrough_whitelist is specified here, don’t specify it in user_variables.yml.
Running the playbooks
The two playbooks responsible for implementing SR-IOV are:
os-neutron-install.yml
os-nova-install.yml
These playbooks will be run as part of setup-openstack.yml or they can be run independently as shown here:
cd /opt/openstack-ansible/playbooks/
openstack-ansible os-neutron-install.yml os-nova-install.yml
Once complete, check the agent list to confirm the SR-IOV agent has checked in:
root@infra1-utility-container-ef7d8189:~# openstack network agent list --agent-type nic
+--------------------------------------+------------------+-------------+-------------------+-------+-------+-------------------------+
| ID | Agent Type | Host | Availability Zone | Alive | State | Binary |
+--------------------------------------+------------------+-------------+-------------------+-------+-------+-------------------------+
| 1a0a3fd7-4b01-4807-ab26-758ec7ec9d8a | NIC Switch agent | hp02-qlogic | None | :-) | UP | neutron-sriov-nic-agent |
| 624c8394-b561-4f08-a362-f18189e41de0 | NIC Switch agent | hp03-2x520 | None | :-) | UP | neutron-sriov-nic-agent |
+--------------------------------------+------------------+-------------+-------------------+-------+-------+-------------------------+
Using SR-IOV
To spin up an instance using SR-IOV, you must first create a port with certain characteristics. The direct port type instructs Neutron to bind the port to an SR-IOV agent on the respective compute to which the instance was scheduled. To create a direct port, use the following syntax:
openstack port create --network vlan101 --vnic-type direct --disable-port-security vm3port
The command creates a direct type of port in the vlan101 network. Port security, including security group rules, cannot be used for ports leveraging SR-IOV and has been disabled.
+-----------------------+-----------------------------------------------------------------------------+
| Field | Value |
+-----------------------+-----------------------------------------------------------------------------+
| admin_state_up | UP |
| allowed_address_pairs | |
| binding_host_id | |
| binding_profile | |
| binding_vif_details | |
| binding_vif_type | unbound |
| binding_vnic_type | direct |
| created_at | 2018-09-21T13:39:53Z |
| data_plane_status | None |
| description | |
| device_id | |
| device_owner | |
| dns_assignment | None |
| dns_domain | None |
| dns_name | None |
| extra_dhcp_opts | |
| fixed_ips | ip_address='192.168.4.18', subnet_id='9493da3b-0b7c-4974-90f0-8f31e6a74bae' |
| id | fb33a32e-7043-45fe-b0af-6d5e799d1183 |
| mac_address | fa:16:3e:30:1b:66 |
| name | vm3port |
| network_id | cc93bbe1-2610-40ee-9594-2f469af07829 |
| port_security_enabled | False |
| project_id | d18bb3908ca84fcbb90a08d2727fc3ef |
| qos_policy_id | None |
| revision_number | 1 |
| security_group_ids | |
| status | DOWN |
| tags | |
| trunk_details | None |
| updated_at | 2018-09-21T13:39:54Z |
+-----------------------+-----------------------------------------------------------------------------+
Next, create the instance and specify the port rather than a network:
openstack server create --key-name test --flavor m1.large.non-numa --image xenial-server-cloudimg-amd64 --nic port-id=vm3port --user-data=cloud.txt --availability-zone nova:hp02-qlogic vm3
The command shown here creates an instance with a standard flavor (4 vCPU, 8GB RAM in this case), a standard Ubuntu Xenial cloud image, and some userdata, and attaches it to the specified port. The VM will be scheduled to the hp02-qlogic (aka compute3) node in this environment.
The output here shows the VM is ACTIVE:
root@infra1-utility-container-ef7d8189:~# openstack server list
+--------------------------------------+------+--------+----------------------+------------------------------+-------------------+
| ID | Name | Status | Networks | Image | Flavor |
+--------------------------------------+------+--------+----------------------+------------------------------+-------------------+
| c24ccc51-0d84-477e-af1d-8f8d9685b3c5 | vm3 | ACTIVE | vlan101=192.168.4.18 | xenial-server-cloudimg-amd64 | m1.large.non-numa |
| 48d30a90-a56a-4b94-967f-61522fff9e46 | vm2 | ACTIVE | vlan101=192.168.4.21 | xenial-server-cloudimg-amd64 | m1.large |
| 475bbed6-758b-454a-8f60-9a57732c0e19 | vm1 | ACTIVE | vlan101=192.168.4.4 | xenial-server-cloudimg-amd64 | m1.large |
+--------------------------------------+------+--------+----------------------+------------------------------+-------------------+
If everything goes as expected, the SR-IOV agent will bind the port to a virtual function that can be observed in the following output:
root@hp02-qlogic:~# ip link show ens2f1
7: ens2f1: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 9000 qdisc mq master ovs-system portid 40a8f02bd8d4 state UP mode DEFAULT group default qlen 1000
link/ether 40:a8:f0:2b:d8:d4 brd ff:ff:ff:ff:ff:ff
vf 0 MAC 00:00:00:00:00:00, tx rate 10000 (Mbps), max_tx_rate 10000Mbps, spoof checking on, link-state auto
vf 1 MAC fa:16:3e:30:1b:66, vlan 101, tx rate 10000 (Mbps), max_tx_rate 10000Mbps, spoof checking on, link-state auto
vf 2 MAC 00:00:00:00:00:00, tx rate 10000 (Mbps), max_tx_rate 10000Mbps, spoof checking on, link-state auto
vf 3 MAC 00:00:00:00:00:00, tx rate 10000 (Mbps), max_tx_rate 10000Mbps, spoof checking on, link-state auto
vf 4 MAC 00:00:00:00:00:00, tx rate 10000 (Mbps), max_tx_rate 10000Mbps, spoof checking on, link-state auto
vf 5 MAC 00:00:00:00:00:00, tx rate 10000 (Mbps), max_tx_rate 10000Mbps, spoof checking on, link-state auto
vf 6 MAC 00:00:00:00:00:00, tx rate 10000 (Mbps), max_tx_rate 10000Mbps, spoof checking on, link-state auto
vf 7 MAC 00:00:00:00:00:00, tx rate 10000 (Mbps), max_tx_rate 10000Mbps, spoof checking on, link-state auto
In this case, vf 1 is associated with the MAC address of the port, fa:16:3e:30:1b:66. A connectivity test should prove successful:
retina-imac:~ jdenton$ ssh ubuntu@192.168.4.18
ubuntu@192.168.4.18's password:
Welcome to Ubuntu 16.04.5 LTS (GNU/Linux 4.4.0-134-generic x86_64)
* Documentation: https://help.ubuntu.com
* Management: https://landscape.canonical.com
* Support: https://ubuntu.com/advantage
Get cloud support with Ubuntu Advantage Cloud Guest:
http://www.ubuntu.com/business/services/cloud
27 packages can be updated.
16 updates are security updates.
New release '18.04.1 LTS' available.
Run 'do-release-upgrade' to upgrade to it.
Last login: Fri Sep 21 18:41:42 2018 from 192.168.1.53
ubuntu@vm3:~$
Drivers
Instances using SR-IOV must be configured with drivers compatible with the underlying network interface card. In the case of the QLogic card used here, the same bnx2x driver that interacts with the underlying physical network card on the compute node can also be installed in the instance to interface with the virtual function:
ubuntu@vm3:~$ ethtool -i ens5
driver: bnx2x
version: 1.712.30-0
firmware-version: bc 7.15.24
expansion-rom-version:
bus-info: 0000:00:05.0
supports-statistics: yes
supports-test: no
supports-eeprom-access: no
supports-register-dump: no
supports-priv-flags: yes
The Ubuntu Xenial cloud image includes this driver by default. Other network cards, such as the Intel X520 or X540, may use separate drivers for the physical and the virtual function (ixgbe and ixgbevf, respectively). The virtio driver cannot be used with SR-IOV.
Gotchas
When SR-IOV is used, the virtual function becomes invisible to the underlying compute node once it is associated with a running instance. Therefore, it becomes difficult to observe traffic passing thru the interface as it traverses the compute node in or out of the physical network infrastructure. Mellanox has (or had) a Ceilometer inspector that could acquire counters from the driver to assist in troubleshooting. Capturing live traffic might be possible using service chaining.
Another alternative involves using macvtap as an intermediary. When a port of type macvtap is specified, a macvtap interface is created on the host and associated with a virtual function:
root@infra1-utility-container-ef7d8189:~# openstack port create --network vlan101 --vnic-type macvtap --disable-port-security vm4port
...
root@infra1-utility-container-ef7d8189:~# openstack server create --key-name test --flavor m1.large.non-numa --image xenial-server-cloudimg-amd64 --nic port-id=vm4port --user-data=cloud.txt --availability-zone nova:hp02-qlogic vm4-macvtap
...
root@hp02-qlogic:~# ip -d link show macvtap0
43: macvtap0@enp8s9f1: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state UP mode DEFAULT group default qlen 500
link/ether fa:16:3e:5a:f6:2e brd ff:ff:ff:ff:ff:ff promiscuity 0
macvtap mode passthru addrgenmode eui64
root@hp02-qlogic:~# ip link show ens2f1
7: ens2f1: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 9000 qdisc mq master ovs-system portid 40a8f02bd8d4 state UP mode DEFAULT group default qlen 1000
link/ether 40:a8:f0:2b:d8:d4 brd ff:ff:ff:ff:ff:ff
vf 0 MAC 00:00:00:00:00:00, tx rate 10000 (Mbps), max_tx_rate 10000Mbps, spoof checking on, link-state auto
vf 1 MAC fa:16:3e:5a:f6:2e, vlan 101, tx rate 10000 (Mbps), max_tx_rate 10000Mbps, spoof checking on, link-state auto
vf 2 MAC 00:00:00:00:00:00, tx rate 10000 (Mbps), max_tx_rate 10000Mbps, spoof checking on, link-state auto
vf 3 MAC 00:00:00:00:00:00, tx rate 10000 (Mbps), max_tx_rate 10000Mbps, spoof checking on, link-state auto
vf 4 MAC 00:00:00:00:00:00, tx rate 10000 (Mbps), max_tx_rate 10000Mbps, spoof checking on, link-state auto
vf 5 MAC 00:00:00:00:00:00, tx rate 10000 (Mbps), max_tx_rate 10000Mbps, spoof checking on, link-state auto
vf 6 MAC 00:00:00:00:00:00, tx rate 10000 (Mbps), max_tx_rate 10000Mbps, spoof checking on, link-state auto
vf 7 MAC 00:00:00:00:00:00, tx rate 10000 (Mbps), max_tx_rate 10000Mbps, spoof checking on, link-state auto
The macvtap interface is then connected to the instance. Because the interface is visible to the underlying OS, utilities such as ifconfig and tcpdump can be used, among others. The instance will fallback to the virtio driver, but will still see a boost in performance compared to bridges since SR-IOV is still leveraged:
ubuntu@vm4-macvtap:~$ ethtool -i ens3
driver: virtio_net
version: 1.0.0
firmware-version:
expansion-rom-version:
bus-info: 0000:00:03.0
supports-statistics: no
supports-test: no
supports-eeprom-access: no
supports-register-dump: no
supports-priv-flags: no
Summary
The use of SR-IOV requires some planning on the part of the deployer and the end user. Dedicated interfaces should be used for SR-IOV. The use of bonding is incompatible with SR-IOV, however, multiple physical interfaces can be mapped to a single provider label. Bonding within an instance may be possible, however, there is no guarantee the virtual functions will be spread across multiple physical interfaces.
End users should also be aware that SR-IOV may complicate live migration efforts. The use of macvtap may simplify that effort, though.
As always, feel free to reach out on IRC in #openstack-ansible or on Twitter at @jimmdenton with any questions, corrections, or criticism =)
